Z-Bar Flashing for Standing Seam - 3m
Cladco Z‑bar flashings for standing seam cladding projects are supplied in 3m lengths, providing essential support and weather sealing where corner barge flashings will be installed. Manufactured from high‑quality SSAB Nordic steel with a durable GreenCoat® Pural BT coating, they’re designed to deliver strong performance and a clean finish on contemporary cladding elevations.
About Our GreenCoat® Pural BT Standing Seam Z‑Bar Flashings
Cladco Z‑bar flashings are designed to provide secure support and weather sealing for standing seam side‑cladding installations. Supplied in 3m lengths, each Z‑bar creates a stable fixing point for corner barge flashings to be clamped to, helping you achieve a neat, modern edge detail on contemporary cladding projects.
Manufactured from high‑quality SSAB Nordic steel and coated in durable GreenCoat® Pural BT, these flashings offer excellent strength, long‑term weather resistance and a consistent finish that integrates seamlessly with our standing seam system.
Benefits of Standing Seam Z‑Bar Flashings
- Provides a stable fixing point for standing seam corner barge flashings
- Supports a smooth, modern appearance with concealed fixings
- Manufactured from A1 fire‑rated SSAB Nordic steel
- Durable GreenCoat® Pural BT coating for long‑lasting protection
- Easy to position and secure using annular ring nails
Specifications
- Length: 3m
- Dimensions: 50mm x 40mm x 30mm
- Thickness: 0.7mm
- Material: SSAB Nordic steel
- Finish: GreenCoat® Pural BT
- Fire Rating: Class A1 (BS EN 13501)
Fixing Guidance
Z‑bar flashings should be fixed vertically along corner edges using annular ring nails suitable for thin‑gauge steel installations. Once secured, they provide the required surface for standing seam corner barge flashings to be clamped in place using seaming pliers. These special pliers are included in our standing seam roofing tool kit.
The standing seam system is designed to conceal fixings for a clean, streamlined finish. However, in exposed or high‑wind locations, you may wish to add reinforcement. For this, we recommend our colour‑matched 6.3x20mm stainless steel or Ruspert®‑coated stitcher screws to support trims where needed. Using these screws will create a visible fixing, but their colour‑matched design keeps the overall appearance consistent.
For more detailed guidance on tools, positioning and installation steps, please refer to our standing seam installation guides.
Looking for an alternative?
For a notched Z-bar flashing, see our Z-bar flashing (notched) for standing seam.
For bespoke requirements, see our custom flashings.
Or browse our roofing department for flashings and more.
For large commercial projects, high volumes or specialist requirements, please call 01837 659901 for expert advice.
Order A Sample Pack!
Download our printable installation guide (1).
Download the datasheet for Z-Bar Flashing for Standing Seam - 3m
