3m Z Bar Flashing Support Polyester Paint Finish (35 x 33 x 35mm)
Achieve a straight, professional roof edge by fixing your barge flashings to this 3m polyester-painted Z‑bar support. Formed to a 35mm × 33mm × 35mm profile, it provides a strong, reliable mounting point for 32/1000 and 34/1000 box profile roofs. The smooth polyester finish, in colours such as juniper green and slate blue, coordinates cleanly with matching metal sheets.
About Our Z‑Bar Flashings in Polyester Paint Finish
When your project requires a dependable way to securely fix your barge flashings in place, this polyester-painted Z‑bar support provides the strong, stable mounting point you need. Formed to 35mm × 33mm × 35mm, the Z‑bar flashing sits beneath the barge flashing to create firm support and a smart, accurate roofline detail.
Manufactured from high‑quality steel with a smooth polyester paint finish, it offers a clean, coordinated look alongside our polyester-painted sheets and accessories. Available in a choice of colours, including black and light grey, it helps you maintain a consistent appearance across the roof.
Benefits of Polyester Paint Z‑Bar Flashings
- Provides strong support for barge flashings
- Smooth polyester paint finish for a coordinated look
- Colour options help match adjacent sheet accessories
- Strong steel profile for lasting rigidity
- Suitable for box profiles and insulated panels
The Z‑bar is designed for use with 34/1000 box profile sheets fitted with 150mm x 150mm barge flashings, and also suits 32/1000 box profile roofs with polyester paint finish barge flashings of any size. It can also be used on insulated panels where extra rigidity is required.
Specifications
- Material: Galvanised steel
- Finish: Polyester paint (smooth)
- Length: 3m
- Profile size: 35mm × 33mm × 35mm
Fixing Guidance
Install the Z‑bar by stitching the bottom flange directly into the roof sheet to form a rigid base. Once fixed, attach the barge flashing to the top flange of the Z‑bar to create a straight, stable roof edge. Handle sheets and flashings carefully; sharp edges can be present. Cut‑resistant gloves (EN388:2016) are recommended during installation.
For clear steps and illustrated best practices, please refer to our roofing installation guides before starting your project.
Looking for an alternative?
For a PVC plastisol Z‑bar, see our 3m Z‑bar flashing support in PVC plastisol.
For a bespoke shape, see our custom flashings.
Or browse our roofing department for flashings and more.
For large commercial projects, high volumes or specialist requirements, please call 01837 659901 for expert advice.
Order A Sample Pack!
Click here to view the online installation guide (1).
Download the datasheet for 3m Z Bar Flashing Support Polyester Paint Finish (35 x 33 x 35mm)
