110° Abutment Flashings in PVC Plastisol Finish - 3m 200mm x 200mm

From £29.40

About this product

Cladco Abutment Flashings with a PVC Plastisol coat provide a durable, scratch-resistant finish for projects with an internal angle such as lean-to buildings. Made from multi-layered steel and with a PVC leather grain finish to complement Cladco Roofing Sheets, these Flashings are available in a wide choice of 11 colours.

Please note images may vary from actual item supplied due to lighting variations and camera angles

Total Price: £29.40 Inc VAT
Add to Basket
Nationwide Delivery
Made In Uk

110° Abutment Flashings in PVC Plastisol Finish - 3m 200mm x 200mm

110° Abutment Flashings in PVC Plastisol Finish - 3m 200mm x 200mm
110° Abutment Flashings in PVC Plastisol Finish - 3m 200mm x 200mm

More about Cladco 3m Abutment Flashings, PVC Plastisol Coating

Cladco 3m Abutment Flashings are manufactured from high-quality, galvanised steel. These Flashings are coated with PVC Plastisol for a damage and scratch-resistant, leather grain finish.

Abutment Flashings are made with a 110-degree internal angle. They are designed to flex 10-15 degrees either way to create a neat finish for a profiled roof or a clad building.

PVC Plastisol has a tough leather grain finish that provides a life in excess of 40 years in normal environments. This coating is available in 11 colours to enhance the look of any structure.

Our steel Abutment Flashings are manufactured with a 10mm safety welt. This improves the strength of the Flashing while increasing your roof’s aesthetics.

Abutment Flashings can be secured to roofing sheets using 22mm Stitching Screws. Please allow for a 200mm overlap to the proceeding Abutment Flashing when fixing.

This Flashing is also available with a Polyester Paint, Prelaq Mica and plain Galvanised coating.

Please note: 200mm x 200mm Flashings provide a coverage of 190mm x 190mm due to the 10mm safety welt.

Length (metres): 3.0
Size: 200mm x 200mm
Safety Welt: 10mm (both sides)
Overlap: Minimum 200mm
Angle: 110º degrees
Colours Available: Anthracite, Black, Chestnut, Goosewing Grey, Slate Blue, Vandyke Brown, Merlin Grey, Juniper Green, Moorland Green, Olive Green and White.

PLEASE NOTE – Extra care should always be taken when handling metal sheets and flashings we advise using the correct type of Glove when handling or moving metal sheets and flashings. Gloves can be purchased on our website.
